JOHNSON FLUITEN旋转接头R038020631技术参数
More Information | ||
Flow | Dual Passage Rotating Syphon | |
Rotor (K) | G 1-1/2" RH (ISO 228-1) | |
Inlet M | G 1-1/2" RH (ISO 228-1) | |
RPM (max) | 1700 | |
Seal Package | B3 | |
Fluid | Water, Air, Hydraulic Oil, Glycol, Coolant | |
Joint Size | 1-1/2" | |
Outlet P | G 3/4" RH (ISO 228-1) | |
Syphon S | 26 MM | |
Joint S type | ROTATING | |
Pressure | 35 | |
Manufacturer | Johnson-Fluiten | |
Country of Origin | Italy | |
Weight | 4.900 kg | |
Temperature (min) | -19°C | |
Temperature (max) | 120°C |
JOHNSON FLUITEN旋转接头R系列其他常用型号:
JOHNSON FLUITEN R038003436
JOHNSON FLUITEN R038003437
JOHNSON FLUITEN R038006621
JOHNSON FLUITEN R038008716
JOHNSON FLUITEN R038012107
JOHNSON FLUITEN R038020607
JOHNSON FLUITEN R038020616
JOHNSON FLUITEN R038020617
JOHNSON FLUITEN R038020631
JOHNSON FLUITEN R038020632
JOHNSON FLUITEN R038020633
JOHNSON FLUITEN R038020671
JOHNSON FLUITEN R038020672
JOHNSON FLUITEN ROTARY UNIONS NEW + ORIGINAL+ ONE YEAR WARRANTY
