TESCOM调节器26-2000系列技术参数
OPERATING PARAMETERS | |
Maximum Inlet Pressure | 10,000 psig / 690 bar |
Outlet Pressure Ranges | 10-1500 psig 0.7-103 bar |
Design Proof Pressure | 150% of rated pressure |
Leakage | Bubble-tight |
Operating Temperature | -15°F to 165°F / -26°C to 73°C |
Flow Capacity | Cv = 0.02, 0.06, 0.12, or 0.30 |
MEDIA CONTACT MATERIALS | |
Body | 316 Stainless Steel or Brass |
Seat, Vent, and Main Valve | Polyimide (Vespel®) |
O-Ring | Nitrile, Buna-N (70 durometer) |
Back-up Ring | PTFE |
Remaining Parts | 316 Stainless Steel and 17-4 PH Stainless Steel |
OTHER | |
Cleaning | CGA 4.1 and ASTM G93 |
Weight (approximate) | 5.5 lbs / 2.5 kg |
TESCOM调节器26-2000系列介绍
26-2000系列高压、低流量活塞感应调节器提供圆顶、弹簧和空气负载版本。该调节器配备了隔离捕获的排气标准，入口压力额定值为 6000-15,000 psig / 413-1034 bar。
特征
标准隔离捕获的排气口
三种标准加载方法 - 弹簧、圆顶和气动
提供柔软和金属对金属座
标准40微米内部过滤器（软座型号）延长使用寿命
可提供Cv为0.30的高流量版本
26-2000 Series high pressure, low flow piston sensed regulator is available in dome, spring and air load versions. This regulator comes with segregated captured venting standard with inlet pressure ratings of 6000-15,000 psig / 413-1034 bar.
Features
Segregated captured vent is standard
Three standard loading methods - spring, dome, and air actuated
Available with soft and metal-to-metal seating
Standard 40 micron internal filter (soft seated models) increases service life
High flow version is available with Cv of 0.30
TESCOM调节器26-2000系列选型
TESCOM调节器26-2000系列其他常用型号：
TESCOM 26-2061D24S270
TESCOM 26-2062D24S270
TESCOM 26-2063D24S270
TESCOM 26-2064D24S270
TESCOM 26-2065D24S270
TESCOM 26-2066D24S270
TESCOM 26-2067D24S270
TESCOM 26-2061D24D270
TESCOM 26-2062D24D270
TESCOM 26-2067D24D270
TESCOM 26-2061D24A270
TESCOM 26-2062D24A270
TESCOM 26-2064D24A270
TESCOM 26-2065A24A370
TESCOM Regulator NEW + ORIGINAL+ ONE YEAR WARRANTY
爱泽工业成立于2010年，定位于向制造工业提供高端制造技术和设备。代理经营世界优质的电气自动化、机械与传动、流体控制、仪器仪表、工具等产品。作为电气，液压以及气动解决方案的合作伙伴，我们利用我们的全球协作团队，为客户提供先进解决方案，市场知识以及相关增值服务来帮助优化客户的工作效率，提高可靠性和安全性，致力于成为工业产品和解决方案的优质渠道。
如果有任何关于TESCOM调节器26-2065A24A370的疑问，请随时与我们沟通（021-31006702）。我们将尽全力解决您的问题。
If you have any question for TESCOM products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:www.ize-industries.com.
TESCOM调节器26-2000系列26-2065A24A370技术参数及选型
