HONEYWELL压力变送器STG775-F1GC4A-1-A-AHS-11S-A-21A0-F1技术参数
Code | STG775-F1GC4A-1-A-AHS-11S-A-21A0-F1 |
KEY NUMBER | STG775: Gauge Dual Head |
Process Head & Diaphragm Materials | F: 316 Stainless Steel, Hastelloy C - 276 |
Fill Fluid | 1: Silicone Oil 200 |
Process Connection | G: 1/2" NPT (female),Same as Process Head |
Bolt/Nuts Materials | C: Carbon Stee |
Vent/Drain Type/Location | 4: |
Gasket Materials | A: Teflon® or PTFE (Glass Filled) |
Head/Connect Orientation | 1: Standard,High Side Left, Ref Side Right2 / Std Head Orientation |
Approvals | A: <FM> Explosion proof, Intrinsically Safe, Non-incendive, & Dustproof |
Electronic Housing Material & Connection Type | A: Polyester Powder Coated Aluminum,1/2 NPT,None |
Output/ Protocol | H: 4-20mA dc,HART Protocol |
Customer Interface Selections | S: Standard(w/Internal Zero,Span&Config buttons),None,EN, RU |
Application Software | 1: Standard Diagnostics |
Output Limit, Failsafe & Write Protect Settings | 1: Disabled,High> 21.0mAdc,Honeywell Std (3.8 - 20.8 mAdc) |
General Configuration | S: Factory Standard |
Accuracy and Calibration | A: |
Mounting Bracket | 2: Angle Bracket, 304 SS |
Customer Tag | 1: One Wired Stainless Steel Tag (Up to 4 lines 26 char/line) |
Unassembled Conduit Plugs & Adapters | A0: No Conduit Plugs or Adapters Required |
Certifications & Warranty | F1: Calibration Test Report & Certificate of Conformance (F3399) |
HONEYWELL压力变送器STG系列介绍
STG700 和 STG70L 是 SmartLine产品系列的一部分，适用于监测、控制和数据采集，采用压阻传感器技术，将压力传感与片上温度补偿功能相结合，在各种应用压力下提供高精度、稳定性和高性能和温度。 SmartLine 系列还经过全面测试并符合 Experion PKS，提供更高水平的兼容性保证和集成功能。 SmartLine可轻松满足压力测量应用苛刻的应用需求。
Part of the SmartLine family of products, the STG700 and STG70L are suitable for monitoring, control and data acquisition featuring piezoresistive sensor technology combining pressure sensing with on-chip temperature compensation capabilities providing high accuracy, stability and performance over a wide range of application pressures and temperatures. The SmartLine family is also fully tested and compliant with Experion PKS providing the highest level of compatibility assurance and integration capabilities. SmartLine easily meets the most demanding application needs for pressure measurement applications.
HONEYWELL压力变送器STG系列选型
HONEYWELL压力变送器STG系列其他常用型号：
HONEYWELL STG77S-E1B000-1-C-BHT-13C-B-01A7-F1/FE/TP-0000
HONEYWELL STG77S-E1G000-1-0-AH0-11S-A-10A0-00-X000
HONEYWELL STG77S-E1G000-1-0-AHS-11C-B-11A0-F1-0000
HONEYWELL STG77S-E1G000-1-0AHS-11S-A-00A0-00-0000
HONEYWELL STG77S-E1G000-1-A-AHA-11S-A-10A0-00-0000
HONEYWELL STG77S-E1G000-1-A-AHS-11S-A-10A0
HONEYWELL STG77S-E1G000-1-A-AHS-11S-A-10A0-00-0000
HONEYWELL STG77S-E1G000-1-A-AHT-11S-A-10A0-02-0000
HONEYWELL STG77S-E1G000-1-A-CHS-11S-A-00A0
HONEYWELL STG77S-E1G000-1-A-AHS-11S-A-00A0
HONEYWELL STG77S-E1G00-1-A-AHS-11S-A-10A0
HONEYWELL STG77S-F1G0001-A-BHS11C-B11A0-F1,F5
HONEYWELL STG77S-F1G000-1-A-EHS-11S-A-10A0
HONEYWELL STG77S-F1G000-1-C-AHS-11S-A-10A0-00-0000
HONEYWELL STG775-F1GC4A-1-A-AHS-11S-A-21A0-F1
