CIRCLE VALVE安全阀D559B-2M技术规格
Specifications | |
Series | 500 |
Variation | Popoff with deflector cap |
Body Material | Brass |
Seal Material1 | Buna N |
Valve Size | 1/4 in |
End Connection | Pipe Thread Male |
Operating Pressure | 0.5 to 150 psig |
Cracking Pressure | 0.5 to 150 psig |
Cracking Pressure Tolerance | ±5% |
Operating Temperature | -65 to 275 ºF |
Proof Pressure | 400 psig |
Rated Burst Pressure | 500 psig |
Dim. L | 1.38 in |
Dim. L1 | 1.20 in |
Hex | 5/8 in |
Dia. D (max.) | 0.90 in |
Weight | .08 lbs |
Optional Body Material | 303 stainless steel |
Optional End Connections | M - Male NPT |
CIRCLE VALVE安全阀D559B-2M介绍
弹出阀或内联阀
可调泄压
零泄漏
可选的工厂预设
准确的设定压力
开启压力范围广
防篡改调整
100% 阀座泄漏测试
注意：建议进行适当的过滤以防止损坏密封面。
“D”型变体：带前缀的零件号配有一个盖子，可将高压冲击从仪器中转移出来，并用作防雨和防尘罩。
Popoff or inline valves
Adjustable crack pressure
Zero leakage
Optional factory preset
Accurate set pressure
Wide range of cracking pressure
Tamper-proof adjustment
100% seat leakage tested
Note: Proper filtration is recommended to prevent damage to sealing surface.
‘D’ Variation: Prefixed part number is supplied with a cap which diverts high pressure blasts from personnel and instruments, and serves as a rain and dust shield.
