REXROTH液压马达A2FE SIZE 56技术参数
Size | 56 | |
Displacement | Vg | 56,1 cm³ |
Speed max. | nmax | 5000 rpm |
nmax intermit. | 5500 rpm | |
Flow max. | qV max | 280 L/min |
Torque constants | TK | 0,89 Nm/bar |
Torque at ∆p = 400 bar | T | 356 Nm |
Rotary stiffness | 440 Nm/° | |
Mass moment of inertia around output shaft | J | 0,0042 kgm² |
Case fill capacity | 0,45 L | |
Weight (approx.) | m | 18 kg |
REXROTH液压马达A2FE系列介绍
– 采用轴向锥形活塞旋转组的固定排量马达，弯轴式设计，适用于开式和闭式液压回路。
– 主要安装在机械齿轮箱中，例如履带驱动（几乎完全集成到机械齿轮箱中，结构极其紧凑）。
– 输出转速取决于泵的流量和马达的排量。
– 扭矩随高低压侧压差和排量的增加而增大。
– 结构紧凑。
– 高效。
– 整机组装完成并经过测试。
– 安装简便，只需“插入”机械齿轮箱即可。
– 无需考虑安装公差。
– Fixed displacement motor with axial tapered piston rotary group of bent axis design, suitable for hydrostatic drives in open and closed circuits.
– Primarily for installation in mechanical gearboxes, e.g. track drives (almost fully integration into a mechanical gearbox, extremely compact unit)
– The output speed depends on the flow capacity of the pump and the displacement of the motor
– The torque increases with the pressure differential between the high and low pressure side and with increasing displacement
– Compact design
– High efficiency
– Complete unit, ready assembled and tested
– Easy assembly, simply „plugs-in“ to mechanical gearboxes
– No installation tolerances to consider
REXROTH液压马达A2FE系列选型
REXROTH液压马达A2FE系列其他常用型号：
REXROTH R902198036 A2FE56/61W-VZL100
REXROTH R909437443 A2FE63/61W-VAL100
REXROTH R909437482 A2FE56/61W-VAL100
REXROTH R909437748 A2FE45/61W-VZL100
REXROTH R909416951 A2FE90/61W-VAL100
REXROTH R909418424 A2FE32/61W-VAL100
REXROTH R909418426 A2FE125/61W-VAL100
REXROTH R909419560 A2FE107/61W-VAL100
REXROTH R909419867 A2FE80/61W-VAL100
REXROTH R909419990 A2FE28/61W-VAL100
REXROTH R909421394 A2FE180/61W-VAL100
REXROTH R902065772 A2FE90/61W-VZL192JS
REXROTH R902078992 A2FE107 61L VXLXX0 S
REXROTH Hydraulic motor NEW + ORIGINAL+ ONE YEAR WARRANTY
爱泽工业成立于2010年，定位于向制造工业提供高端制造技术和设备。代理经营世界优质的电气自动化、机械与传动、流体控制、仪器仪表、工具等产品。作为电气，液压以及气动解决方案的合作伙伴，我们利用我们的全球协作团队，为客户提供先进解决方案，市场知识以及相关增值服务来帮助优化客户的工作效率，提高可靠性和安全性，致力于成为工业产品和解决方案的优质渠道。
如果有任何关于REXROTH液压马达R902198036 A2FE56/61W-VZL100的疑问，请随时与我们沟通（021-31006702）。我们将尽全力解决您的问题。
If you have any question for REXROTH products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:www.ize-industries.com.
REXROTH液压马达A2FE系列R902198036 A2FE56/61W-VZL100技术参数及介绍
