OLAER蓄能器DA-075-210ABAF1125是ELM 0.75-210/85/AF的升级型号
OLAER蓄能器DA-075-210ABAF1125技术参数
Technical Specifications | |
Product Series: | DA Series (formerly ELM) |
Product Type: | Diaphragm / Membrane Accumulator |
Gas Volume: | up to 3.5 L |
Maximum Operating Pressure: | up to 350 bar |
Specifications Met: | PED2014/68/EU or Article 4.3 |
Valve Port Size: | Gas side : (Nitrogen rechargable) M28 x 1.5, |
Body Material: | Carbon Steel |
Elastomer: | NBR nitrile standard rubber |
Minimum Operating Temperature: | from -35 °C |
Maximum Operating Temperature: | up to +80 °C |
Weight: | 0.7 to 16.5 kg |
Height: | 112 to 326 mm |
Diameter: | 64 to 180 mm |
Accessories Included: | Clamps, LockNuts & Charging Kits |
OLAER蓄能器DA系列介绍
DA 蓄能器系列配有粘合密封 (BS) 流体端口，具有内螺纹或外螺纹和内螺纹流体连接以及 M28x1,5 气体连接。
特点/优点：
• 采用由膜片蓄能器组成的液压减震器，提高了驾驶员的舒适度，并在驾驶时提供即时响应时间越过障碍物或崎岖的地形。
• DA 隔膜蓄能器为液压系统提供了一种经济有效的解决方案。
• DA 隔膜蓄能器符合PED 标准，可在超过35 个国家/地区使用。
• DA 隔膜蓄能器提供高压缩比（高达 8 – 根据类型）
• 低维护产品
DA accumulator range comes with a bonded seal (BS) fluid port with female or male and female fluid connection and M28x1,5 gas connection.
Features/Benefits:
• The adaption of a hydraulic shock absorber made up of a diaphragm accumulator improves driver comfort and offers immediate response times when driving over obstacles or rough terrain.
• The DA diaphragm accumulator offers a cost effective solution for hydraulic systems.
• The DA diaphragm accumulators are PED compliant and can be used in over 35 countries.
• The DA diaphragm accumulators offer high compression ratio (up to 8 – according to type)
• Low maintenance product
OLAER蓄能器DA系列选型
OLAER蓄能器DA系列其他常用型号：
OLAER DA00725000AF1102000
OLAER DA01625000AF1102000
OLAER DA03221000AF1102000
OLAER DA05021000AF1102000
OLAER DA07521000AF1102000
OLAER DA10021000AF1102000
OLAER DA14014090AF1102000
OLAER DA20025090BF1102000
OLAER DA28025090BF1102000
OLAER DA35025090BF1102000
OLAER DA-075-210ABAF1125
OLAER DIAPHRAGM ACCUMULATORS NEW + ORIGINAL+ ONE YEAR WARRANTY
爱泽工业成立于2010年，定位于向制造工业提供高端制造技术和设备。代理经营世界优质的电气自动化、机械与传动、流体控制、仪器仪表、工具等产品。作为电气，液压以及气动解决方案的合作伙伴，我们利用我们的全球协作团队，为客户提供先进解决方案，市场知识以及相关增值服务来帮助优化客户的工作效率，提高可靠性和安全性，致力于成为工业产品和解决方案的优质渠道。
如果有任何关于OLAER蓄能器DA-075-210ABAF1125的疑问，请随时与我们沟通（021-31006702）。我们将尽全力解决您的问题。
If you have any question for OLAER products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:www.ize-industries.com.
OLAER蓄能器DA系列DA-075-210ABAF1125技术参数及选型
