SEW变频器MDX61B0075-5A3-4-0T技术参数
Unit designation | MDX61B0075-5A3-4-0T |
Series | 61 = Options can be installed |
Version | B |
Recommended motor power | 0075 = 7.5 kW |
Supply voltage | 5 = AC 380 ... 500 V |
Radio interfer-ence suppression on the line side | A = Radio interference suppression C2 |
Connection type | 3 = 3-phase |
Quadrants | 4 = 4Q (with brake chopper) |
Type | 0T = Application |
SEW变频器MOVIDRIVE MDX60B/61B系列介绍
MOVIDRIVE®驱动逆变器的紧凑设计节省了控制柜的空间，其高用户友好性保证了参数化期间的时间，而智能IPOSplus®定位和序列控制作为标准。
在驱动逆变器中的大量输入和输出确保了一个合格的基本功能。可选的通信和技术模块提供了快速和方便的扩展。
The compact design of the MOVIDRIVE® drive inverter saves space in the control cabinet, while its high user-friendliness ensures that you save time during parametrization, while the intelligent IPOSplus® positioning and sequence control is included as standard.
A multitude of inputs and outputs in the drive inverter ensure a competent basic functionality. Optional communication and technology modules provide for quick and easy extension.
SEW变频器MOVIDRIVE MDX60B/61B系列选型
SEW变频器MOVIDRIVE MDX60B/61B系列其他常用型号：
SEW MDX61B-0011-5A3-4-0T
SEW MDX61B-0040-5A3-4-0T
SEW MDX61B-0150-5A3-4-0T
SEW MDX61B-0220-5A3-4-0T
SEW MDX61B-0300-5A3-4-0T
SEW MDX61B-0370-5A3-4-0T
SEW MDX61B-0450-5A3-4-0T
SEW MDX61B-0550-5A3-4-0T
SEW MDX61B-0750-5A3-4-0T
SEW MDX61B-0900-5A3-4-0T
SEW MDX61B-1100-503-4-0T
SEW MDX61B-1320-503-4-0T
SEW MDX61B-0075-5A3-4-0T
SEW Drive Inverter NEW + ORIGINAL+ ONE YEAR WARRANTY
爱泽工业成立于2010年，定位于向制造工业提供高端制造技术和设备。代理经营世界优质的电气自动化、机械与传动、流体控制、仪器仪表、工具等产品。作为电气，液压以及气动解决方案的合作伙伴，我们利用我们的全球协作团队，为客户提供先进解决方案，市场知识以及相关增值服务来帮助优化客户的工作效率，提高可靠性和安全性，致力于成为工业产品和解决方案的优质渠道。
如果有任何关于SEW变频器MDX61B0075-5A3-4-0T的疑问，请随时与我们沟通（021-31006702）。我们将尽全力解决您的问题。
If you have any question for SEW products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:www.ize-industries.com.
SEW变频器MDX61B0075-5A3-4-0T技术参数及选型
