COSMO测漏仪LS-1866 A1V技术参数
Differential Pressure | Minimum Reading | 0.1Pa |
Leak Rate Display Range | 0.00～±999 （Pa、mL/min）（Auto Range） | |
Limit Setting Range | 0～±999 | |
Channel Number | 16 | |
Timer Setting Range | 0～999.8 s (999.9 s means no time limitation) | |
Power Source | AC100～240V±10% 50/60Hz Power Consumption 70VA | |
Pressure Source | Clean air sufficiently higher than the test pressure. | |
Pilot Pressure Source | Clean air from 400～700kPa | |
Tubing Port Inner Diameter | Rc1/4（Pressure Source, WORK and Master Ports）, 6mm one-touch joint (Pilot pressure source) (Pressure Range M, L is connected to Pressure source by 6mm tube) | |
Communication Function | Serial Port RS-232C (Print mode is available) | |
Ambient Temperature･Humidity | 5 to 40℃、80%RH max, but no condensation | |
Weight | Approx 6.3kg (H Type: Approx. 8kg) | |
Standard Equipment and Accessory | (Standard) Regulator, Oil-mist separator, Filter regulator for Pilot regulator (Accessory) Quick attachment bracket, Inspection report, Operation manual | |
COSMO测漏仪LS系列产品参数介绍及选型
The LS-1866 A1MG.VK is a DP air leak tester for testing the airtightness of all types of components/products, and allows for the automation of the leak testing process
●Equipped with high sensitivity/highly pressure resistant DP sensor as well as a heat resistant air controlled valve
●The basic circuit, a high-performance, exceptionally safe intelligent air circuit runs checks on valve operation and sensor sensitivity during each test.
●The master preset function and NR mode function make possible an improvement in detection ability and a decrease in test times.
●Channel functions are also available, allowing for compatibility with many types of workpieces.
LS-1866 A1MG.VK是DP空气泄漏测试仪，用于测试所有类型的组件/产品的气密性，并允许泄漏测试过程的自动化
●配备高灵敏度/高耐压DP传感器以及耐热空气控制阀
●在每次测试过程中，基本电路都是高性能，特别安全的智能空气回路，用于检查阀门的运行情况和传感器的灵敏度。
●主预设功能和NR模式功能可提高检测能力并减少测试时间。
●还可以使用通道功能，以兼容多种类型的工件。
COSMO测漏仪LS系列其他型号：
COSMO LS-902
COSMO LS-R700
COSMO LS-1866 A1V
COSMO LS-1866 A1MG.VK
COSMO LS-R910
COSMO LS-R740 (SH)
COSMO LS-R740 (SS)
COSMO LS-1866
