SUN阀FDCB-LAN技术参数
Technical Data | |
Cavity | T-5A |
Series | 2 |
Capacity | 12 gpm |
Maximum Operating Pressure | 5000 psi |
Adjustment - No. of CCW Turns from Fully Closed to Fully Open | 5 |
Valve Hex Size | 1 1/8 in. |
Valve Installation Torque | 45 - 50 lbf ft |
Adjustment Screw Internal Hex Size | 5/32 in. |
Locknut Hex Size | 9/16 in. |
Locknut Torque | 80 - 90 lbf in. |
Model Weight | 0.61 lb. |
Seal kit - Cartridge | Buna: 990203007 |
Seal kit - Cartridge | EPDM: 990203014 |
Seal kit - Cartridge | Viton: 990203006 |
SUN阀FDCB-LAN产品介绍
具有逆流检查功能的完全可调、压力补偿流量控制可为可能存在较大压力波动的入口节流或出口节流应用提供精确的流量调节。它们可以从几乎关闭到流量上限进行无级调节。集成的大容量止回阀可提供从端口 2 到端口 1 的不受限制的流量。
• 所有 2 端口流量控制插芯在物理和功能上均可互换（即，对于给定的框架尺寸，具有相同的流路、相同的腔体）。然而，阀从安装表面延伸的尺寸可能会有所不同。
• 平衡调节机构即使在高压下也能轻松调节。
• 锋利的孔口设计更大限度地减少了由于粘度变化而引起的流量变化。
• 当调节机构转到关闭位置时，最小泄漏量为 0.2 gpm (0.8 L/min)。
• 配置有 EPDM 密封件的阀芯适用于含有磷酸酯液体的系统。接触石油基液体、油脂和润滑剂会损坏密封件。
Fully adjustable, pressure-compensated flow controls with reverse-flow check provide precise flow regulation for meter-in or meter-out applications where there may be wide pressure fluctuations. They are infinitely adjustable from nearly closed up to the maximum flow. An integral high-capacity check valve provides unrestricted flow from port 2 to port 1.
• All 2-port flow control cartridges are physically and functionally interchangeable (i.e. same flow path, same cavity for a given frame size). However, cartridge extension dimensions from the mounting surface may vary.
• A balanced adjustment mechanism allows for easy adjustment even at high pressures.
• The sharp-edged orifice design minimizes flow variations due to viscosity changes.
• Minimum leakage is .2 gpm (0,8 L/min) when the adjustment mechanism is turned to the shut-off position.
• Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
SUN溢流阀FDCB系列其他常用型号：
SUN FDCBLAN
SUN FDCBLAV
SUN FDCBLBV
SUN FDCBLBN
