SUN阀RPGD-ABN技术参数
Technical Data | |
Cavity | T-3A |
Series | 2 |
Capacity | 50 gpm |
Maximum Operating Pressure | 2000 psi |
Pilot Ratio | 0.834027778 |
Maximum Valve Leakage at 110 SUS (24 cSt) | 3 in³/min.@1000 psi |
Maximum Air Pressure | 150 psi |
Response Time - Typical | 10 ms |
Valve Hex Size | 1 1/8 in. |
Valve Installation Torque | 45 - 50 lbf ft |
Model Weight | 0.53 lb. |
Seal kit - Cartridge | Buna: 990203007 |
Seal kit - Cartridge | Polyurethane: 990003002 |
Seal kit - Cartridge | Viton: 990203006 |
SUN阀RPGD-ABN产品介绍
空气控制、先导式、平衡活塞减压阀芯使用隔膜上的压缩空气而不是可调节弹簧来控制压力设置。 空气信号通过盒六角端的端口提供。 它们是常闭压力调节阀。 当入口（端口 1）处的压力达到阀门设定值时，阀门开始向油箱（端口 2）打开，节流流量以调节压力。 这些阀门准确，压力上升与流量较低，平稳安静，速度适中。
• 所有2 端口泄压阀芯（先导泄压阀除外）在物理和功能上均可互换（对于给定的框架尺寸，具有相同的流路、相同的腔体）。
• 端口2 可接受最大压力； 适用于跨端口泄压电路。
• 最大气压不应超过150 psi (10 bar)。
• 采用Sun 浮动式结构，最大限度地减少由于安装扭矩过大和/或型腔/盒加工变化而导致内部零件粘连的可能性。
Air-controlled, pilot-operated, balanced piston relief cartridges use compressed air over a diaphragm instead of an adjustable spring to control pressure setting. The air signal is supplied through a port in the hex-end of the cartridge. They are normally closed pressure regulating valves. When the pressure at the inlet (port 1) reaches the valve setting, the valve starts to open to tank (port 2), throttling flow to regulate the pressure. These valves are accurate, have low pressure rise vs. flow, they are smooth and quiet, and are moderately fast.
• All 2-port relief cartridges (except pilot reliefs) are physically and functionally interchangeable (same flow path, same cavity for a given frame size).
• Will accept maximum pressure at port 2; suitable for use in cross port relief circuits.
• Maximum air pressure should not exceed 150 psi (10 bar).
• Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
SUN阀RPGD系列其他常用型号：
SUN RPGD-ABN
SUN RPGD-ABV
SUN RPGD-AIN
SUN RPGD-AIV
SUN RPID-BBN
SUN RPKD-BBN
SUN RQEB-LAN
SUN RQGB-LAN
SUN RQIB-LAN
SUN RQKB-LAN
